SPEC NO: DSAK8207 REV NO: V.4B DATE: MAR/26/2013 PAGE: 2 OF 6
APPROVED: WYNEC CHECKED: Allen Liu DRAWN: F.Cui ERP: 1101027506
Selection Guide
Absolute Maximum Ratings at TA=25癈
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
3. 5mm below package base.
Part No.
Dice
Lens Type
iewing
Angle [1]
Min.
Typ.
2?/2
WP7113VBC/D
Blue (InGaN)
Water Clear
3500 6000
20?/SPAN>
Iv (mcd) [2]
@ 20mA
Parameter
Blue
Units
Power dissipation
120
mW
DC Forward Current
30
mA
Peak Forward Current [1]
100
mA
Reverse Voltage
5
V
Operating/Storage Temperature
-40癈 To +85癈
Lead Solder Temperature [2]
260癈 For 3 Seconds
Lead Solder Temperature [3]
260癈 For 5 Seconds
Notes:
1. ?/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value.
2. Luminous intensity/ luminous Flux: +/-15%.
3. Luminous Intensity value is traceable to the CIE127-2007 compliant national standards.
Electrical / Optical Characteristics at TA=25癈
Notes:
1.Wavelength: +/-1nm.
2. Forward Voltage: +/-0.1V.
3.Wavelength value is traceable to the CIE127-2007 compliant national standards.
Symbol
Parameter
Device
Typ.
Max.
Units
Test Conditions
籶eak
Peak Wavelength
Blue
465
nm
IF=20mA
籇 [1]
Dominant Wavelength
Blue
470
nm
IF=20mA
敾1/2
Spectral Line Half-width
Blue
22
nm
IF=20mA
C
Capacitance
Blue
100
pF
VF=0V;f=1MHz
VF [2]
Forward Voltage
Blue
3.3
4
V
IF=20mA
IR
Reverse Current
Blue
50
uA
VR = 5V
